SCORPIO V
Stabilized: Yes
Weight: 72 lbs (33 Kg)
Max Payload: 100 lbs (45 Kg)
Range: Pan ±360°, Tilt ±270°
Speed: 360°/ 2.8 sec
Underslung Min Height: 35 5/16” (89.7 cm)
Underslung Min Width: 25” (64 cm)
Underslung Min Depth: 20 3/4” (52.7 cm)
Overslung Min Height: 22 7/8” (58 cm)
Overslung Min Width: 25” (64 cm)
Overslung Min Depth: 20 3/4” (52.7 cm)
SCORPIO V
Building on the principles and engineering of the Scorpio Classic stabilized head, the design and capabilities of the new gyros, new mechanics and new software makes the Scorpio V faster, easier, and more effective. Faster in terms of pan speeds up to 360º in 2.8 seconds with HD slip rings and the speed of adjustment to head size and configuration. Easier to control stability, drift, and horizon with tech-friendly usability.
The Scorpio V’s effective level of stabilization incorporates new mechanics and electronics designed to detect a broad rangeof frequencies of vibrations and with enough speed to correct faster than other heads.
Measuring at 25 inches wide and 20 inches deep, the Scorpio V head has a minimum underslung height of 35 5/16 inches and a minimum overslung height of 22 7/8 inches. It has a maximum camera payload of 100 pounds.
Like its predecessor, the Scorpio V offers a full size frame for quick and easy camera installation with little limitation with larger payloads, programmable limits, backpan compensation, wireless capability, and motion repeatability (even in stabilization mode).
THE SCORPIO V MINI
Stabilized: Yes
Weight: 47 lbs (21.32 Kg)
Max Payload: 45 lbs (20 Kg)
Range: Pan/Tilt ±360°, Roll ±360°
Speed: Pan/Tilt/Roll 360°/ 2 sec
Underslung Height: 21” (54 cm)
Underslung Width: 18” (45 cm)
Underslung Depth: 19” (48 cm)
Overslung Height: 19” (48 cm)
Overslung Width: 18” (45 cm)
Overslung Depth: 19” (48 cm)
The Scorpio V Mini
The Scorpio V Mini stabilized head sets a new level of stabilization in the small size and weight category. Building on the principles and engineering of the Scorpio V stabilized head, the design and capabilities of the new gyros and mechanics, combined with new software makes this head small and light with strong stabilization and capacity. The Scorpio V Mini’s stabilization is designed to detect a broad range of frequencies of vibrations and with enough speed to correct faster than other heads.
This 3-axis head can carry up to 45 pounds of camera payload, and can be controlled using handwheels, a joystick, or a pan bar. It is possible to program repeatable movements, limits, dampening, and speed adjustments for all axes. The dimensions of the Scorpio V Mini are 21 inches tall underslung or 19 inches tall overslung, 18 inches wide, and 19 inches deep.
SCORPIO CLASSIC STABILIZED 4 - AXIS
Lorem ipsum odor amet, consectetuer adipiscing elit. Ipsum nostra senectus tortor vitae senectus varius condimentum. Enim non porta ligula interdum vel porttitor vel volutpat. Malesuada tincidunt accumsan tempus morbi maximus mi. Semper scelerisque vivamus; ligula elit accumsan volutpat. Ante mollis euismod odio risus taciti nibh cubilia a. Convallis nulla eros sit eget quis. Ut ligula suscipit, suspendisse faucibus nisi placerat. Justo elementum dictum mauris nec duis lectus facilisi at.
Proin vitae tempor ultricies malesuada ad magnis malesuada lacus odio. Vulputate massa nullam cras iaculis per. Mus rhoncus commodo pretium dapibus sagittis. Erat pulvinar sed curae odio potenti viverra vestibulum nullam. Tincidunt curae morbi phasellus nisl; etiam varius vel. Gravida lobortis maecenas nullam quis magna vulputate ultrices nullam. Vulputate curae pulvinar fusce elementum malesuada libero non. Eros luctus pretium in tempus habitant interdum.
SCORPIO CLASSIC STABILIZED 4 - AXIS
Proin vitae tempor ultricies malesuada ad magnis malesuada lacus odio. Vulputate massa nullam cras iaculis per. Mus rhoncus commodo pretium dapibus sagittis. Erat pulvinar sed curae odio potenti viverra vestibulum nullam. Tincidunt curae morbi phasellus nisl; etiam varius vel. Gravida lobortis maecenas nullam quis magna vulputate ultrices nullam. Vulputate curae pulvinar fusce elementum malesuada libero non. Eros luctus pretium in tempus habitant interdum.
Eget gravida mus pulvinar nibh blandit leo sem. Sapien dictum non laoreet tellus aliquam dapibus. Nec parturient tellus rhoncus himenaeos feugiat. Vestibulum vehicula dignissim cursus nostra nisi. Sed lobortis nullam aptent donec fames malesuada elit. Aliquet commodo curabitur tempus faucibus efficitur fermentum congue. Lacus aliquam mollis scelerisque nibh a ex lobortis. Ullamcorper fringilla vel suscipit viverra consectetur parturient ultricies? Dui integer massa quam interdum, ante cubilia euismod!
Ornare donec lacinia viverra hendrerit iaculis? Feugiat suspendisse etiam; sit ridiculus libero quisque cras. Euismod gravida egestas hac sed ultrices libero felis arcu. Integer justo porta cubilia gravida; per tempor convallis maecenas. Nam lorem sapien mi ridiculus volutpat mus suscipit. Placerat lorem tellus magna habitasse nunc. Scelerisque bibendum nisi ultrices metus enim placerat. Facilisis ipsum ipsum ligula accumsan arcu venenatis maecenas.
MATRIX 4 AXIS GIMBAL
Eget gravida mus pulvinar nibh blandit leo sem. Sapien dictum non laoreet tellus aliquam dapibus. Nec parturient tellus rhoncus himenaeos feugiat. Vestibulum vehicula dignissim cursus nostra nisi. Sed lobortis nullam aptent donec fames malesuada elit. Aliquet commodo curabitur tempus faucibus efficitur fermentum congue. Lacus aliquam mollis scelerisque nibh a ex lobortis. Ullamcorper fringilla vel suscipit viverra consectetur parturient ultricies? Dui integer massa quam interdum, ante cubilia euismod!
Ornare donec lacinia viverra hendrerit iaculis? Feugiat suspendisse etiam; sit ridiculus libero quisque cras. Euismod gravida egestas hac sed ultrices libero felis arcu. Integer justo porta cubilia gravida; per tempor convallis maecenas. Nam lorem sapien mi ridiculus volutpat mus suscipit. Placerat lorem tellus magna habitasse nunc. Scelerisque bibendum nisi ultrices metus enim placerat. Facilisis ipsum ipsum ligula accumsan arcu venenatis maecenas.
MATRIX 4 AXIS GIMBAL
The Matrix is a 4-axis gimbal that features an open architecture and one redundant axis. This allows the gimbal to be mounted in any orientation and still maintain polarity of pan, tilt and roll without experiencing gimbal lock. It is the only 4 axis gimbal to offer 360 continuous roll without a patch cable between the twist and tilt axis.
There are two primary operating modes. The image relative mode allows you to operate in relation to the image on the monitor and does not relate to earth’s horizon. This allows the operator to focus on the subject rather than on whether the pan axis will become the roll axis halfway through the shot. Earth relative mode acts in relation to earth’s horizon and will always maintain a level horizon even in high G-force conditions.
MOVI XL
System Type: 3 axis gyro stabilized
Head Weight: 25 lbs
Max Payload: 50 lbs
Pan Limit: 360°
Tilt Limit: +90°/-170°
Roll Limit: +/- 90°
Pan Speed: 200° per sec.
Tilt Speed: 200° per sec
Roll Speed: 200° per sec
Operating Temp: -4° F to 122° F
Power Requirements: 22V DC
Min. dims: 27.5” T x 20” W x 26” D
Controls: Wireless Mimic & MōVI Controller
Opt: Handwheels, Wireless Video
MOVI XL
Lorem ipsum odor amet, consectetuer adipiscing elit. Ipsum nostra senectus tortor vitae senectus varius condimentum. Enim non porta ligula interdum vel porttitor vel volutpat. Malesuada tincidunt accumsan tempus morbi maximus mi. Semper scelerisque vivamus; ligula elit accumsan volutpat. Ante mollis euismod odio risus taciti nibh cubilia a. Convallis nulla eros sit eget quis. Ut ligula suscipit, suspendisse faucibus nisi placerat. Justo elementum dictum mauris nec duis lectus facilisi at.
Proin vitae tempor ultricies malesuada ad magnis malesuada lacus odio. Vulputate massa nullam cras iaculis per. Mus rhoncus commodo pretium dapibus sagittis. Erat pulvinar sed curae odio potenti viverra vestibulum nullam. Tincidunt curae morbi phasellus nisl; etiam varius vel. Gravida lobortis maecenas nullam quis magna vulputate ultrices nullam. Vulputate curae pulvinar fusce elementum malesuada libero non. Eros luctus pretium in tempus habitant interdum.
Stabilized: Yes
Weight: 11 lbs (5 Kg)
Max Payload: 30 lbs (13.6 Kg)
Range: Pan 360°, Tilt ±135°, Roll ±30°
Max Speed: Pan 400°/s, Tilt/Roll 360°/s
Max Op Temp: -4°F-122°F (-20°C-50°C)
Underslung Min Height: 20.9” (53 cm)
Underslung Min Width: 13.8” (35 cm)
Underslung Min Depth: 16.4” (41.6 cm)
Ronin 2
Ronin 2
The Ronin 2 gimbal is DJI’s advanced camera movement system designed to maximize shooting time in several different configurations. This mountable and hand-held stabilized gimbal is a lightweight and portable system that many professional filmmakers rely on for creating high quality productions.
An update from the original Ronin, this motorized stabilization system is suitable for a range of camera and lens configurations, boasting a payload capacity of 30 pounds. This means it can be used for everything from DSLRs up to cinema cameras such as the ARRI ALEXA Mini or Sony FS7. Upgraded high-torque motors allow the gimbal to support a wider range of cameras, resist high winds and G-forces caused when mounted onto a car, and keep it moving smoothly in flight.
Like its predecessor, the Ronin 2 features support for underslung, upright, and briefcase operation modes to help you achieve the best angle. However, it has been redesigned to enable easy transition between upright and underslung modes without changing the position of the camera. It also offers several other improvements, such as enhancements to the control software and physical design to simplify taking complex shots without sacrificing performance, all while making important functions more readily accessible.
Egripment 306
Stabilized: NO
Type: remote
Maximum load: 35 kg
Width: 39,8 cm
Depth: 16,5 cm
Height: 35 cm
Weight: 12 kg
Minimum speed: 360 ° / 48 min
Maximum speed: 360 ° / 3 sec
The 306 is a compact and completely nodal remote head with a load capacity of 35 kg | 77 lbs. The 306 head is very fast and offers the smooth response and reliability that Egripment heads are known for.retfg
Egripment 306
The Scorpio 10’ is a two-part telescopic crane with tilt, pan, and arm encoder reading for high-quality motion capturing. The two-section arm is designed for operator flexibility and offers a universal fit to attach to any dolly.
The maximum lens height is 15’4” overslung with a telescoping range of 7’7”, extending and retracting as fast as 6’ per second. The base width can adjust from 2’1” to 3’2” with a minimum door clearance of 5’8”. The full extended arm reach is 10’6,” and the retracted reach is 2’11”. The overall arm length extended is 14’4”.
The Scorpio 10’ has two different operation modes: electronic and manual. The default electronic mode allows telescopic electronic movement, powering the crane by batteries and warranting high precision, smooth footage in low and high-speed movements. The manual mode gives control to the Camera Operator to move the telescopic arm and create unique shots that match their vision.
One of the unique features of the Scorpio 10 is the “Arc compensation,” which automatically corrects the arc generated by motion, both in horizontal and vertical movement, keeping the camera line straight. Additionally, the Scorpio 10 features back panning through the system’s advanced software capabilities. This crane has added value to the creative vision of filmmakers for years while also adding production value and extended functionality to those behind the camera
